WORKING HEIGHT 6m
SEMI BATTERY VERTICAL LIFT
| SPECIFICATIONS | |
|---|---|
| Max. Working Height | 6,00m |
| Max.Platform Height | 4,00m |
| Basket Dimensions | 84cmx69cm |
| Main Body lmpression | 130cmx7lcm |
| Safe Working Load | 150Kg. |
| Max. PowerExpended | 250N |
| Working lnclination | 0' |
| Max Wind Force | 0mph |
| Max. Wheel Load | 250 Kg |
| Working Sound | 80Dba |
| CLOSED DIMENSIONS | |
|---|---|
| Lenght | 130cm. |
| Width | 71cm. |
| Height | 201cm |
| Weight | 350 kg. |
| BATTERY CHANGER SPECIFICATION | |
|---|---|
| lnputVoltage | 180-265V AC |
| Freguency | 45-65 HZ |
| Output | 24 V DC 7/8A |
| POWER SOURCE/LIFTING | |
|---|---|
| Gear Box Motor | 800W /24v |
| Hydraulic Pump | 10cl.lx302 |
| Hydraulic Tank | 6 lt. |
| BATTERY SPECIFICATION | |
|---|---|
| Battery Type | Dry Type |
| Battery Voltage | 24 V |
| Battery Power | 100Ah |
