Vertical Lift
TCL 3002
WORKING HEIGHT 5.50m
FULL BATTERY
SPECIFICATIONS
Max. Working Height
5,50m
Max.Platform Height
3,30m
Basket Dimensions
84cmx69cm
Main Body lmpression
130cmx7lcm
Safe Working Load
150Kg.
Max. PowerExpended
250N
Working lnclination
0'
Max Wind Force
0mph
Max. Wheel Load
250 Kg
Working Sound
80Dba
CLOSED DIMENSIONS
Lenght
130cm.
Width
71cm.
Height
201cm
Weight
460 kg.
BATTERY CHANGER SPECIFICATION
lnputVoltage
180-265V AC
Freguency
45-65 HZ
Output
24 V DC 7/8A
POWER SOURCE/LIFTING
Gear Box Motor
800W /24v
Hydraulic Pump
10cl.lx302
Hydraulic Tank
6 lt.
BATTERY SPECIFICATION
Battery Type
Dry Type
Battery Voltage
24 V
Battery Power
l00Ah
POWER SOURCE/DRIVE
Gear Box Motor
550W
Gear Ratio
1:50
Motor Brake
24Kgf-cm
CONTROLLER
Controller Power
l00 Ah
Joystick Power
l00 Ah
Conroller Brand
TCLIFT
×
